Over Engineered Fridge Handle, Will Outlive Fridge
Print Profile(2)
Description
https://www.buymeacoffee.com/maxt
----------------------
| Print with 3-5 walls, 30% infill, fuzzy skin for better grip (0.8 point distance, 0.3 thickness) |
No more fridge fumbles. No more cursing. Just cold confidence. Print once, forget forever.
This Fridge Handle represents a robust and ultra-durable refrigerator handle, intentionally designed to exceed typical strength and longevity requirements. Its geometry is optimized for functionality, precision mounting, and heavy-duty use.
Key Specifications:
Mounting Hole Distance (center-to-center): 152 mm (Short) and 175 mm (Long)
Width (at widest point): 75 mm
Total Height (approx.): 190 mm (Short) and 212 mm (Long)
Depth: ~34 mm
Top and Bottom Spacing (from mounting holes): ~28 mm
This handle is intended for retrofit or custom fridge door applications where mechanical strength, ergonomic grip, and durability are key. The model’s construction ensures it can withstand substantial mechanical stress—likely outliving the refrigerator it’s mounted to.
The short version is a replacement for the following part: https://quickparts.dk/doergreb/1011907/ and it's suitable for:
| SCANDOMESTIC: | SKS 261 A++, SKS 200-1A++, SKF 220-1A++ |
| SCANCOOL: | SKS 260 A+, SKS 260 A+, SKF 220-1A++ VERSION2, SKF 220, KS 250 A+ |
| HAKA: | LMH235 |
| ATLAS: | KS195A, KS 251A++, KS 250 A, KFS 213 A++ |
The long version is a replacement for the following part: https://quickparts.dk/doergreb-til-koeleskab/1013495/ and it's suitable for:
| SCANDOMESTIC: | SKS 261 A++, SKS 200-1A++, SKF 220-1A++, SKF 205A++, SFS206-1A++, SFS 162A+ |
| SCANCOOL: | SKS 260 A+, SKF 220 A+ |
| ATLAS: | KS 251A++, KS 197A++ |
