ASG Steyr SSG 69 P2 magazine extension
Print Profile(1)
Bill of Materials
- M2,6 x 9 screw x 2: https://nl.aliexpress.com/item/1005009155507332.html
- M1,7 x 12 screw x 2: https://nl.aliexpress.com/item/1005009155507332.html
- 0.3mm, 250mm, 5mm spring x 1: https://nl.aliexpress.com/item/1005008680306079.html
- 0.2mm, 5mm, 2mm spring x 2: https://nl.aliexpress.com/item/1005003880136210.html
Description
assembly: put the stift at the end of the way and push the case together but leave a gap at the bbs entry point to to slide later the pusher. assemly the pusher together and put it on one side of the long spring and the other side of the spring can ggo in the case. fiddle the pusher in the case.
u schould now be able to push the case together and if u wish can already schrew it together. now get the two small springs behind the slider and push the slider frome the side of the case (its only fit in one way and need some force).
if u didnt already screw it now together.
