Death Star | 34 step puzzlebox (SPIN-OFF SERIES)

Disclaimer

This 3D printable model created by 2222pzzls is fan-made art inspired by iconic items from films.

These models are provided free for personal, non-commercial use only. 2222pzzls is not affiliated with, endorsed by, or involved with the studios, or intellectual property owners associated with these items and holds no legal rights to them. Users must ensure compliance with applicable copyright and trademark laws.

-

DEATH STAR | 34 Step Puzzlevault

Note:

This is part of my Himitsu Bako 2 | Spin-off series. That means the puzzle is the same as Himitsu Bako 2, only with different themes!

The next of the the HIMITSU BAKO 2 | OFFICIAL SPIN-OFF SERIES!

Risen from the cold steel of the void — the second in the Himitsu Bako 2 spin-off: Himitsu Bako II — DEATH STAR Edition. Clad in battle-ready metal and panels hewn as if from the Death Star itself, this intricate puzzle demands 34 precise shifts of hidden plates and secret corridors to unseal its core. Evade the patrols, outwit the Alliance’s rivals, and trace routes across planets.


Only a true Rebel — daring, cunning, and relentless — can crack the code of the villain himself and break into his vault. Will you be the one to awaken what lies within the iron heart of the galaxy?

-

Do you like my puzzles? Please consider a (small) donation. Every contribution helps me keep experimenting, designing, and releasing new puzzles for everyone to enjoy at no cost. Thank you so much.

Or you can:

Attention:
This model contains moving parts and relies on tight tolerances. It is strongly recommended to print using a relatively new or well-maintained nozzle. Worn or heavily used nozzles may result in inaccurate prints, which can cause parts to fuse together or fail to meet the required tolerances. This may prevent components from moving correctly or cause them to become stuck.

Compatibily & Information

• NO AMS NEEDED!
• NO ADDITIONAL PARTS NEEDED!
• NO GLUE NEEDED!
• A1 MINI COMPATIBLE - Even for Multi Color (exept for AMS printprofile)
• Dimensions (outer) 150 x 150 x 95 mm
• Dimensions (inner) 120 x 110 x75 mm
  • Enough room to store valuables  :)

Print instructions

• BAMBULAB Filament is highly recommended!
  • Other brands like Elegoo give very bad results in tolerances (which causes fitting issues!)
• Clean build plate after each printed plate! (for best adhesion)
• Choose you print profile
  • Normal / Tight fit of Loose fit (If you encounter tolerance issues)
    • Multi Color without AMS (with baked in pauses to change filament)
    • AMS (Not A1 Mini Compatible, because of prime towers)
    • Attention! BOX IS SAME IN BOTH PROFILES!
      • The rails of the panels are different (so only reprint the panels if you need to)
• Just press print!

Assembly instructions

• Follow the detailed Parts & Assembly document I included with this model
• No Glue or Additional parts needed!

Solution

• Because this box is pretty hard with 34 steps to open, I included a separate SOLUTION document.
• BE ADVISED! Dont open if you do want to figure out this puzzlebox by yourself!

PS. Have you checked out the PREQUAL of this puzzlebox yet? If you think 34 steps is a bit too much for you, HIMITSO BAKO (the first) has ‘only’ 17 steps to solve.

If you don't like this theme, you can try the official Himitsu Bako 2 with ornate Japanese Patterns or the first of the spin-off series ‘The Tutankhamun’.
