Winnie the Pooh Christmas Baubles - HueForge

A Christmas-themed cartoon ornament designed for multi-color printing through filament swaps. Both models have a diameter of approximately 93 mm.

Three versions are included: a five-color model, a four-color model and a two color model. Print profiles are provided for 0.4 mm and 0.2 mm nozzles.

Results may still be acceptable even if your filament colors are slightly different, but this is not guaranteed. Share your print results and feedback so others can benefit from your experience.


⚠️⚠️ The hole for attaching a string is created using a negative cylinder added in Bambu Studio. It can be removed entirely, resized, or repositioned as needed to fit your preferred hanging method. The STL version comes without the hole, so add it manually if required.

Use the following instructions exactly as specified for your chosen setup. Select the correct nozzle size (0.2 mm or 0.4 mm) and the correct color version (two-color, four-color or five-color) and follow the corresponding swap layers without deviation.

FIVE COLORS VERSION - 0.2 mm nozzle
⚠️ Print Settings five colors version – 0.2 mm nozzle ⚠️
• Infill: 100%
• Layer height: 0.08 mm
• First layer: 0.1 mm
• No supports required

⚠️ Swap Instructions five colors version – 0.2 mm nozzle ⚠️
• Start with Charcoal (black)
• Layer 10 (0.82 mm): Grass Green
• Layer 11 (0.9 mm): Jade White
• Layer 16 (1.3 mm): Scarlet Red
• Layer 19 (1.54 mm): Lemon Yellow
• Layer 23 (1.86 mm): Jade White for the rest

FIVE COLORS VERSION - 0.4 mm nozzle

⚠️ Print Settings five colors version – 0.4 mm nozzle ⚠️
• Infill: 100%
• Layer height: 0.08 mm
• First layer: 0.2 mm

• No supports required

⚠️ Swap Instructions five colors version – 0.4 mm nozzle ⚠️
• Start with Black
• Layer 9 (0.84 mm): Grass Green
• Layer 10 (0.92 mm): Jade White
• Layer 15 (1.32 mm): Scarlet Red
• Layer 18 (1.56 mm): Lemon Yellow
• Layer 22 (1.88 mm): Jade White for the rest

FOUR COLORS VERSION - 0.2mm nozzle

⚠️ Print Settings four colors version – 0.2 mm nozzle ⚠️
• Infill: 100%
• Layer height: 0.08 mm
• First layer: 0.1 mm
• No supports required

⚠️ Swap Instructions four colors version – 0.2 mm nozzle ⚠️
• Start with Charcoal (black)
• Layer 9 (0.74 mm): Scarlet Red
• Layer 13 (1.06 mm): Lemon Yellow
• Layer 18 (1.46 mm): Jade White for the rest

FOUR COLORS VERSION - 0.4mm nozzle

⚠️ Print Settings four colors version – 0.4 mm nozzle ⚠️
• Infill: 100%
• Layer height: 0.08 mm
• First layer: 0.2 mm
• No supports required

⚠️ Swap Instructions four colors version – 0.4 mm nozzle ⚠️
• Start with Charcoal (black)
• Layer 8 (0.76 mm): Scarlet Red
• Layer 12 (1.00 mm): Lemon Yellow
• Layer 17 (1.48 mm): Jade White for the rest

TWO COLORS VERSION - 0.4mm nozzle

⚠️ Print Settings two colors version – 0.4 mm nozzle ⚠️
• Infill: 100%
• Layer height: 0.08 mm
• First layer: 0.2 mm
• No supports required

⚠️ Swap Instructions two colors version – 0.4 mm nozzle ⚠️
• Start with Charcoal (black)
• Layer 11 (1.00 mm): Jade White for the rest

TWO COLORS VERSION - 0.2mm nozzle

⚠️ Print Settings two colors version – 0.2 mm nozzle ⚠️
• Infill: 100%
• Layer height: 0.08 mm
• First layer: 0.1 mm
• No supports required

⚠️ Swap Instructions two colors version – 0.2 mm nozzle ⚠️
• Start with Charcoal (black)
• Layer 12 (0.98 mm): Jade White for the rest
