Modern Woven Christmas Heart

This model is my modern 3D-printed interpretation of the classic Danish julehjerte — the woven Christmas heart made famous by H.C. Andersen.
I kept the iconic woven pattern but redesigned the shape with clean, minimalist lines that print beautifully in PLA.

These ornaments are lightweight, durable, and ideal for both single-color and AMS two-color printing.

🎄 Features

• Modern minimalist version of the classic woven Christmas heart
• Prints beautifully with a 0.4 mm nozzle
• No supports needed
• Perfect for multi-color AMS printing (red + white is especially beautiful)
• Very low filament usage
• Available in 2 mm and 4 mm versions

🧵 Print Settings (0.4 mm Nozzle)

Printer: Bambu Lab A1
Material: PLA Basic (single- or multi-color)
Bed type: Textured PEI
Supports: None
Prime tower: Enabled (for multi-color)

Recommended Quality

• Layer height: 0.16–0.20 mm
• Initial layer: 0.20 mm
• Walls: 2–3
• Top layers: 4–6
• Bottom layers: 4–5
• Top/bottom pattern: Monotonic
• Infill: 15% Gyroid (not important for these models)

Adhesion

• No brim needed
• Skirt: optional

The model is flat and sticks well without additional adhesion helpers.

🎨 Multi-Color (AMS)

The hearts are designed to work perfectly in two colors:

• Color A → outer frame
• Color B → woven grid

Classic combinations:
❤️ White + Red
💙 White + Blue
💛 Red + Gold

But any contrasting colors look great.

📏 Thickness Options

• 2 mm version: Light and elegant
• 4 mm version: Strong, more premium look

Both thicknesses are included.

💡 Tips

• A textured plate gives a soft, matte finish that suits Christmas ornaments well.
• These print very fast, so they are great for batch printing or as small gift sets.
• Use a simple ribbon or twisted string for the traditional Scandinavian look.

📁 Files Included

• Several heart variations in 2 mm
• Several heart variations in 4 mm
• AMS-friendly layout
