Fully parametric box (optional holes)
Print Profile(1)
Description
GREAT NEWS: The new version of the design now includes the ability to create custom holes (of any desired diameter) on each side of the box, including base and lid. Perfect for cable entry, sensors, connectors, or fans!
📦 Versatile Parametric Box for Electronics and DIY Projects!
Are you looking for a robust and customizable enclosure for your next electronic project, an IoT sensor, or simply a component container? Look no further!
This box has been designed to be fully parametric, which means you can adapt it perfectly to your specific needs. Forget standard containers that never fit: with this design, you'll have complete control over dimensions and features.
✨ Key Features
- Fully Parametric: Adjust the main dimensions (A and B) and total height to perfectly fit your circuits (PCBs, Arduino, Raspberry Pi, etc.) or content.
- Robust Screw Closure: The lid securely attaches to the base with screws to ensure reliable closure and protect your components from dust and impacts.
- Simplified Assembly: Screw holes are integrated into the base for quick and precise assembly.
- Clean Design: Simple lines and rounded corners (parameter fillet diameter) for a professional look and increased structural strength.
- Thick Walls: The parameter wall thickness allows you to choose the ideal sturdiness, ensuring strength and durability.
⚙️ Parameters You Can Customize
Thanks to the parametric design, you have control over the following aspects:
| Parameter | Description |
|---|---|
| Dimension A / Dimension B | The dimensions of the box base (length and width). |
| Total height | The height of the box, including the lid height. |
| Wall thickness | The thickness of the box sides for sturdiness. |
| Screw column section | The thickness of the internal columns for screw housing. |
| Hole diameter / Screw countersink diameter | To adapt to different screw sizes you have available. |
| Lid height | To define how thick or deep the lid will be. |
| Fillet diameter | To round external and internal edges. |
| Custom holes NEW | Sets the diameter for holes on the sides, base, and lid. |
🔨 Printing Instructions
- Recommended Material: PLA, PETG, or ABS (if heat resistance is needed).
- Infill: customized according to need.
- Layer Height: 0.2 mm (ideal for details and speed).
- Supports: Not necessary
🔩 Material Needed for Assembly
To securely close the lid to the base, you will need 4 self-tapping screws with a diameter appropriate to the parameters you have set.
💡 Usage Tips
This box is perfect for:
- Arduino/ESP32/Raspberry Pi Projects
- Power Supplies or LED Drivers
- Home Automation Systems (DIY)
- Battery Enclosures
Don't forget to share a photo of your finished project and tell me how you used your custom box!
What do you think? Do you want me to add or modify any specific details of your design?
