Graffiti Lamp – Pop Art Light Decor

Graffiti Lamp – Pop Art

Liquid transition => New model

This light-up decorative object blends graffiti energy with pop art aesthetics, transforming bold shapes and vibrant colors into a sculptural statement piece.


Inspired by street art culture, it captures the raw spontaneity of sprayed paint while maintaining a clean, modern silhouette.

When illuminated from the inside, the object comes alive with a soft ambient glow, enhancing its organic forms and graphic presence. Light flows through the volumes like frozen motion, creating a dynamic contrast between solid structure and luminous expression.

Designed as both a decorative lamp and an art object, it fits naturally on a desk, shelf, or interior display, somewhere between urban sculpture, art toy, and modern design piece.

A bold accent for contemporary spaces, made to stand out, even when the light is off.

_____________________________________________________________________________________

Each part has been designed to allow easy and flexible orientation customization during assembly. A MH001 lamp can be inserted into the base of the graffiti spray can to illuminate the interior and highlight the text.

A cable passage is included. The MH001 housing has been designed with an optimized tolerance to hold the lamp securely without glue. However, depending on the filament type (and its shrinkage characteristics), the fit may slightly vary. If needed, light sanding or a small drop of glue can be used. Using a model made of multiple assembled parts also allows for a wide range of color combinations, giving you full freedom to customize the look according to your preferences.

I can’t wait to see your color and filament combinations 🙂

Printing Recommendations & Important Settings

It is essential to use the provided 3MF file and strictly follow the slicer settings to achieve the best results.

Special attention must be given to the supports on the outer shell. Incorrect support settings may cause breakage or surface damage when removing them after printing. The parameters listed below have been extensively tested to ensure easy assembly and a clean final finish.

👉 Finishing tip: once the model is fully assembled, applying a thin layer of epoxy is highly recommended to achieve a glossy finish and enhance the pop art look.

Part-Specific Settings

🔹 Outer Shell

• Infill density: 0%
• Wall count: 2
• Supports: enabled
• Seam position: rear
• Thin walls: enabled
• Top / bottom surface pattern: concentric
• Solid infill pattern: concentric
• Support Z distance: ≥ 0.4 mm
• Support interface layers: ≥ 1
• Support interface pattern: concentric
• Support / object XY distance: 0.5 mm

🔹 Inner Cylinder

• Infill density: 0%
• Wall count: 1
• Seam position: rear
• Top / bottom surface pattern: concentric
• Solid infill pattern: concentric
• Supports: not required

🔹 Spray Object

• Infill density: 5%
• Wall count: 2
• Top surface pattern: concentric
• Supports: disabled

🔹 Base Cap

• Infill density: 8%
• Wall count: 2
• Seam position: rear
• Top surface pattern: concentric
• Supports: not required

🔹 Cap

• Infill density: 8%
• Wall count: 2
• Seam position: rear
• Top surface pattern: concentric
• Bottom surface pattern: rectilinear
• Solid infill pattern: concentric
• Supports: not required

🔹 Spray Button

• Infill density: 6%
• Wall count: 2
• Seam position: rear
• Supports: enabled
• Top surface pattern: concentric
• Infill pattern: rectilinear

🔹 Bubble Base

• Infill density: 5%
• Wall count: 2
• Seam position: rear
• Top surface pattern: concentric

Print Quality Settings (Important)

For the spray object and the bubble base, variable layer height was applied to improve surface quality:

• Quality / speed setting: 0.5
• Radius: 5

This adjustment enhances surface smoothness and visual detail on highly visible areas.
