Transparent Lyric Speaker
Print Profile(0)
Description
Updated STL version drawings
This model is designed according to the iPad2 internal screen dimensions and needs to be used with an iPad2 internal screen and driver board
Required Bill of Materials:
1. iPad2 internal screen (disassembled screen), requires separating the backlight and LCD panel
2. iPad2 internal screen driver board, requires a 12V DC power interface https://e.tb.cn/h.RgcIFd0CiG4CfQb?tk=GEwy5zezHZn
3. 2 speakers, Jing Ge Yuan square 3-inch speaker; 4 ohms 5W; Product size: 78*78*21mm. https://e.tb.cn/h.RgcKj84whF8IBuJ?tk=Moer5zewoAk
4. AUX Bluetooth decoding amplifier board, requires support for AUX input and 2x 5W speaker output, needs to support Type-C power supply https://e.tb.cn/h.RTrQMkykHVNYyq6?tk=ld4Y5zeCmvR
5. AUX audio cable, 3.5mm male-to-male cable
6. TV box, system must be Android 9.0, able to install and run NetEase Cloud Music TV
7. HDMI flexible flat cable, requires a cable length of 15-20cm https://e.tb.cn/h.R6ywfmlbFhygBGA?tk=k8yS5zV0d2p
8. PD decoy cable, Type-C to 12V DC
9. DC 1-to-2 splitter cable
