Parametric Profile Matrix (Bosch Style T Slot)

🇺🇸 English

Stop buying expensive aluminum rails – print your own! 🛠️

This fully parametric generator lets you create custom construction profiles in the exact style of Bosch-Rexroth and Item directly within the MakerWorld Customizer. The model strictly preserves the original industrial geometry, ensuring that standard T-nuts, M5 screws, and hardware fit and slide perfectly.

⚠️ CRITICAL NOTE: This model is exclusively designed for T-slot plates and T-nuts! It is NOT compatible with V-slot / V-groove systems or V-wheels.

⚙️ Features:

• 📐 T-Slot Standard Only: Tailored specifically for standard T-nuts. Not suitable for V-groove hardware.
• 🔢 All Series Supported: Easily switch between 10, 20, 40, and 60 series standards.
• 🌐 Infinite Matrix Grid (X/Y): Create multi-slot grids (e.g., 40x80 or massive 60x120 configurations) via a simple grid selection.
• ➕ Solid Support Cross: A smart, built-in internal cross structure fuses multi-element profiles together for extreme rigidity.
• 🎛️ Fully Flexible: Customize the total length and internal strut thickness smoothly via sliders.
• 🖨️ 3D Print Optimized: Finely tuned circle resolutions ensure seamless slicing without manifold errors.

💡 Tip: For structural use, print with PETG, ASA, or PC using at least 4 wall loops (perimeters) for maximum strength!

🇩🇪 German

Forget expensive aluminum – print your own profiles yourself! 🛠️

With this fully parametric generator, you can create precisely fitting construction profiles in the style of Bosch-Rexroth and Item directly in the MakerWorld Customizer. The model retains 100% of the original geometry, so standardized T-nuts, M5 screws, and accessories fit and slide perfectly.

⚠️ IMPORTANT NOTE: This model is exclusively designed for T-slot plates and T-nuts! It is NOT compatible with V-slot / V-groove systems or V-wheels.

⚙️ Features:

• 📐 T-Slot Standard Only: Specifically optimized for classic T-nuts. Not suitable for V-slot accessories.
• 🔢 All Series Supported: Supports the most common industrial standards: 10, 20, 40, and 60 series.
• 🌐 Infinite Matrix Grid (X/Y): Create entire profile grids (e.g., a 40x80 or a massive 60x120 profile) via a simple grid selection.
• ➕ Solid Support Cross: An intelligent, integrated support cross connects the segments in multiple grids rock-solid for maximum stability.
• 🎛️ Fully Flexible: Length and wall thickness of the internal struts are continuously adjustable in the Customizer.
• 🖨️ 3D Print Optimized: Perfectly tuned circle resolutions guarantee clean slicing without geometry errors.

💡 Tip: It's best to use PETG, ASA, or PC and print with at least 4 wall loops (perimeters) for maximum strength!

🇨🇳 Simplified Chinese (Chinese)

No need to buy expensive aluminum profiles – print your own exclusive rails directly! 🛠️

This fully parametric generator allows you to create custom assembly profiles that meet Bosch (Bosch-Rexroth) and Item industrial standards directly in the MakerWorld Customizer. The model strictly retains the original official geometric proportions, ensuring that standard T-nuts, M5 screws, and various accessories fit perfectly and slide smoothly.

⚠️ IMPORTANT NOTE: This model is designed exclusively for T-slot plates and T-nuts, and is NOT compatible with V-slot / V-groove systems or V-wheels!

⚙️ Features:

• 📐 T-Slot Standard Only: Optimized specifically for standard T-nuts, not suitable for V-wheels or V-slot accessories.
• 🔢 All Series Supported: Easily switch between 10, 20, 40, and 60 series industrial standards with one click.
• 🌐 Infinite Matrix Grid (X/Y): Multi-slot combined grids can be created (e.g., 40x80 or massive 60x120 specifications) through simple row and column selection.
• ➕ Solid Support Cross: A smart, built-in cross support structure securely fuses multi-unit profiles, providing extreme bending strength.
• 🎛️ Fully Flexible: Total length and internal connection wall thickness can be continuously adjusted in the Customizer.
• 🖨️ 3D Print Optimized: Carefully fine-tuned circular resolutions ensure smooth slicing without topological errors.

💡 Printing Recommendation: For structural parts, it is highly recommended to use PETG, ASA, or PC filament, and set at least 4 wall loops (perimeters) for maximum strength!
