FreeZ 1/28 RWD miniz style prototype
Print Profile(1)
Bill of Materials
- cerchi e gomme per miniz x 4:
- motore f130 o brushless 1410 x 1:
- regolatore x 1:
- servo 4.3g x 1:
- differenziale miniz 64p 53t x 1:
- pignone 64p 11t x 1:
- damper glracing x 4:
- viti m2 x 20:
- 3mm ball end x 10:
- 1.6mm link x 6:
- batterie 1s 350mah x 2:
- ricevente x 1:
- t-plate MM x 1:
Description
Hello everyone, this is a project I'm enjoying in my free time, currently it's still under refinement but it is printable and functional,
it is designed to be economical, functional with readily available materials and compatible with various standard components of the mini world.
For the joints I used 3mm spheres with 1.6mm thread and 1.6mm steel rods used for piercings easily available on aliexpress,
it is possible to use an F130 brushed motor or a 1410 brushless motor.
I have added an assembly guide.
